XTOOL D9s

Description

The XTOOL D9S is a high-level diagnostic platform designed for professional technicians and busy multi-brand workshops.

The D9S combines a large 9.7-inch display with wireless communication, topology mapping, active testing, key-related functions, ECU coding and advanced service capabilities.

Its topology interface gives technicians a visual overview of electronic modules and their communication relationships.

Key Features
9.7-inch professional diagnostic tablet
Wireless vehicle communication
Full-system OE-level diagnosis
Full bi-directional active testing
Topology Mapping
ECU coding
Offline programming on selected manufacturers
Key-programming functions
45+ service functions in current product information
Live-data graphing
Eight simultaneous data streams
Live-data recording/playback/export
AutoVIN
CAN FD
DoIP
Pre-scan/Post-scan capability where supported
Three-year software update period
Diagnostic Functions
ECU identification
Read DTCs
Clear DTCs
Freeze-frame reading
Live-data monitoring
Active component tests
Module scanning
Vehicle network visualization
Diagnostic reporting
Common Service Functions
Oil reset
Electronic parking brake
Steering angle calibration
ABS bleeding
BMS reset
Injector coding
DPF regeneration
Throttle adaptation
TPMS functions
Transmission adaptations
Suspension calibration
Other manufacturer-specific functions
Hardware
Android 10
9.7-inch 1024 × 768 touchscreen
Quad-core 1.5GHz processor
128GB storage
8MP rear camera
USB Type-C
Wi-Fi communication
6400mAh battery
CAN FD
DoIP
Best For
Busy repair workshops
Diagnostic centres
Advanced automotive electricians
Multi-brand automotive workshops
Workshops requiring topology and ECU programming/coding features

Hardware note: XTOOL has published more than one RAM configuration for regional/revision-specific D9S units. AFKG should publish the RAM specification shown on the actual supplied unit rather than assuming all D9S units are identical.
