XTOOL D7s

Description

The XTOOL D7S is a professional 7-inch automotive diagnostic scanner designed for mechanics, automotive electricians, technicians and repair workshops that need comprehensive vehicle diagnostics without moving to a larger flagship platform.

The D7S provides OE-level full-system diagnostics, allowing the technician to communicate with available electronic control modules throughout the vehicle. Depending on the vehicle, this can include the engine, transmission, ABS, SRS/airbag, BCM, steering, HVAC, parking brake, instrument cluster, TPMS and many other systems.

Beyond basic fault-code reading, the D7S offers full bi-directional control, meaning it can send commands to supported control modules and activate components directly. This makes it possible to distinguish between electrical, mechanical and control-module faults much faster.

It also supports ECU coding and module-related procedures on compatible manufacturers, as well as modern vehicle protocols including CAN FD and DoIP.

Key Features
OE-level full-system vehicle diagnostics
Full bi-directional/active testing
4,000+ active tests depending on vehicle coverage
ECU coding on supported vehicles
Online and offline coding support
PMI/module installation functions on supported vehicles
39+ reset, relearn, calibration and maintenance functions
AutoVIN vehicle identification
Complete OBD-II diagnostics
Live-data graphing
Display up to 8 live-data parameters simultaneously
Live-data recording and playback
Freeze-frame data
Diagnostic reports
CAN FD compatibility
DoIP compatibility
FCA Secure Gateway support where applicable
Wi-Fi software updates
Three years of free software updates
Common Diagnostic Functions
Read ECU/module information
Read diagnostic trouble codes
Clear diagnostic trouble codes
Read freeze-frame data
View real-time/live sensor data
Graph live data
Perform actuator tests
Perform component activation
Auto Scan vehicle systems
AutoVIN identification
Common Service Functions

Functions vary according to vehicle make, model and year, but include procedures such as:

Oil service reset
Electronic Parking Brake reset
Steering Angle Sensor calibration
ABS bleeding
Battery Management System reset
DPF regeneration
Injector coding
Throttle relearn
TPMS reset
Gearbox/transmission adaptation
Suspension calibration
Window initialization
Seat calibration
Headlight adjustment
Gear learning
Power-balance procedures
Other vehicle-specific resets and adaptations
Technical Specifications
Operating System: Android 10
Display: 7-inch touchscreen
Resolution: 1024 × 600
Processor: Quad-core 1.5GHz
Memory: 2GB RAM + 64GB storage
Vehicle Connection: Wired
Charging: USB Type-C
Modern Protocols: CAN FD / DoIP
Software Updates: Wi-Fi
Free Updates: 3 years
Best For
Independent workshops
Automotive electricians
Professional mechanics
Mobile mechanics
Diagnostic technicians
Multi-brand repair shops

The D7S is particularly suitable for workshops that want significantly more capability than a standard code reader while retaining a compact, portable design.
